Made in collaboration with Monotrail this module as a dynamic random generator featuring interpolation between points, resembling a complex, ever-changing LFO. Its design comprises two identical smooth random voltage generators, each equipped with frequency, level, offset, and curve controls. The frequency control establishes a consistent pace for generating bipolar random voltages, while the level control functions as an attenuator/Voltage-Controlled Amplifier (VCA). Offset shifts the voltage wave within the range, and curve shapes the interpolation. LEDs visualize bipolar activity on main and gate outputs. CV inputs with attenuators facilitate external modulation, with internal connections for easy cross-modulation. Output VCAs enable nuanced, time-based modulation, eliminating the need for external VCAs. Additional outputs include inverted versions and pulse outputs, facilitating stereo effects, random triggers, and event triggering. Average outputs from both channels offer further versatility.
Video: https://youtu.be/9PxVmeMrOoQ
Product Specs
- Item Number: 31752
- Make: ADDAC System
- Model: ADDAC507
- Condition: Brand New
- Finish: Black
- Categories: keyboards-and-synths ⇒ eurorack
- Function: Clock Generator CV Modulation Dual/Stereo Random
- Made In: Portugal
- MPN: ADDAC507
- Modular Grid: Eurorack ⓘ ＋
- Dimensions*: 10 HP 45 mm deep
- Power*: 70 mA +12V 40 mA -12V 0 mA 5V
* User contributed details
