An in-depth and versatile semi-modular mono synth, the Circadia was developed by a team of heralded synth wizards to be a stand-alone instrument capable of both nuanced sounds and seriously, weird and wonderful sounds that with a flick of a slide (accidental or not) or the removal of a patch cable - soulful low end can turn into oscillating mess.
Featuring:
- Performance-oriented, "East and West" Coast modern analog semi-modular format
- 101 x jacks (plus 10 on rear), 34 x sliders, 16 x knobs, 28 x switches, 36 x LEDs and 5 buttons
- 2 x precision analogue VCOs (VCOA has TZ-FM with INDEX VCA, PWM and SOFT/HARD sync options)
- Eurorack compatible signal levels
- Liquid-sounding, cascaded 4-Pole multimode filter with extensive modulation options and unique modes
- ENV A: Versatile ADSR / AHDSR envelope generator with HOLD function and dynamic level/time control
- ENV B: Complex, beat syncable, multimode function generator with Envelope, LFO, and Burst generator modes
- Triple analog LFO with linked, divisible rates and CV control
- Comprehensive and precise MIDI to CV and GATE implementation with additional synced/tapped LFO and CLOCK outputsÂ
- Six channel waveform mixer with asymmetric soft clippingÂ
- Extensive utility section that includes Noise, S&H, Envelope Follower, Attenuverter, Buff Mults, Summer, Inverters, and connection to a digital potentiometer based guitar pedal expression control interface.
- Analogue ring modulator
- Parallel “West Coast” style wavefolding ability
- Auxiliary VCA and 4-Pole Diode Ladder VCF combination for additional dynamics
- External effect send/return loop with line or guitar pedal levels and wet/dry mix
- Global output drive circuit with bypassable asymmetric soft clipping
- Balanced 1/4" line inputs and outputs plus a dedicated headphone output
- Very Compact (fits in a backpack) and durable powder-coated enclosure with bespoke oak wood sides.
Includes 14 assorted patch cables, USB-A to USB-C cable & an international power supply.
Video: https://youtu.be/upB-27GIGPA
Product Specs
- Item Number: 27048
- Make: Intellijel
- Model: Cascadia
- Condition: Brand New
- Finish: Dark Grey
- Categories: keyboards-and-synths ⇒ digital-synths
- Made In: Canada
- MPN: CASCADIA-DRKGRY
