The M185 is the most intuitive and playable Eurorack sequencer. It appeals as a hands-on performance orientated module for easy creation of complex melodic sequences. It is the original multi-step-per-stage sequencer that inspired the Metropolis and Metropolix modules.
- Features an expansion header for chaining two M185s for 16 stage sequences
- Loads of quantisation scales
- Live X0X style Gate Pattern programming
OVERVIEW
- 8 unique gate modes for creative rhythmic possibilities
- A/B split mode for two separate sequences, like having two sequencers in one box
- 2 channels of CV/GATE and MIDI I/O
- 15 Quantise scales [ NEW for 2021 ] OR pure analogue microtonal CV output
INPUTS & OUTPUTS
- 2 channels of CV and Gate outputs
- Expansion header to connect two M185s for 16 stage sequences [ NEW for 2021 ]
- Reset input [ shared with MIDI input ]
- Sync output [ shared with CH2 gate ]
- Bidirectional Clock I/O
- MIDI input for MIDI clock in, MIDI note transpose
- MIDI output for MIDI clock out, MIDI note output
STAGE DETAILS
- 8 stages, each with individual 1-8 step repeats per stage
- 8 gate modes per stage [ Off, Once, All, 1/2, 1/3, 1/4, Probability or Programmable, and Long ]
- Programmable gate patterns for 'on the fly' X0X style programming of gate triggers
Includes CH2 CV/GATE cable.
Video: https://youtu.be/QuZjsGDVuZQ
Product Specs
- Item Number: 22461
- Make: RYK Modular
- Model: M185
- Condition: Brand New
- Finish: Black
- Categories: keyboards-and-synths ⇒ eurorack
- Function: Sequencer MIDI Clock Generator Controller CV Modulation Function Generator Random
- Made In: United Kingdom
- MPN: RYK-M185
- Modular Grid: Eurorack ⓘ ＋
- Dimensions*: 30 HP 25 mm deep
- Power*: 110 mA +12V 10 mA -12V 0 mA 5V
* User contributed details
