Featuring five ground isolated power outlets, each outlet is capable of 9Vdc at 500mA to keep your pedals performing at their peak. Works as a standalone power supply for smaller pedalboards or can be daisy-chained with our LVL 12 for those tone fanatics with larger boards.
FEATURES
- 5 ground isolated outputs each capable of 9Vdc @ 500mA
- Global mains input voltage (100-240Vac) 50/60Hz for use anywhere in the world
- Standard IEC mains voltage connector
- Dimensions: Width: 3.35" (85mm), Height: 1.65" (42mm), Depth: 5.17" (131.3mm)
- Cable kit included
- 2 x 2.1mm barrel connector 24" (60cm) length
- 4 x 2.1mm barrel connector 18" (45cm) length
- 1 x 2.1mm barrel connector 12" (30cm) length
- 1 x 2.5mm to 2.1mm barrel
- 1 x 2.5mm to 2.1mm barrel reverse polarity
- 1 x 3.5mm TS to 2.1mm barrel
- 1 x 9V Battery clip to 2.1mm barrel
Product Specs
- Item Number: 17074
- Make: Fender
- Model: LVL5 Engine Room Isolated Power Supply
- Condition: Brand New
- Finish: Grey Metallic
- Categories: effects-and-pedals ⇒ pedalboards-and-power-supplies ⇒ pedal
- Made In: China
- MPN: 0230103005
- UPC: 885978685486
