The Eminence Swamp Thang 150 Watt, 8 Ohm provides a thick and chunky tone with loads of sustain. The bottom end will hold up to even the most demanding drop-tune or 7 string players.
SPECIFICATIONS
- Nominal Basket Diameter: 12", 305 mm
- Nominal Impedance: 8 Ω
- Watts: 150 W
- Resonance: 97 Hz
- Usable Frequency Range: 70 Hz - 4 kHz
- Sensitivity: 102 dB
- Magnet Weight: 59 oz.
- Gap Height: 0.312", 7.9 mm
- Voice Coil Diameter: 2", 51 mm
MOUNTING INFORMATION
- Recommended Enclosure Volume
- Sealed: Acceptable
- Vented: Acceptable
- Driver Volume Displaced: 0.079 cu.ft. / 2.25 liters
- Overall Diameter: 12.03", 305.6 mm
- Baffle Hole Diameter: 11.07", 281.2 mm
- Front Sealing Gasket: Yes
- Rear Sealing Gasket: Yes
- Mounting Holes Diameter: 0.25", 6.4mm
- Mounting Holes B.C.D: 11.59", 294.4mm
- Depth: 5.2", 132.1 mm
- Net Weight: 11.1 lbs, 5.03 kg
- Shipping Weight: 12.8 lbs, 5.81 kgs
MATERIALS OF CONSTRUCTION
- Coil Construction: Copper voice coil
- Coil Former: Polyimide former
- Magnet Composition: Ferrite magnet
- Core Details: Non-vented core
- Basket Materials: Pressed steel basket
- Cone Composition: Paper cone
- Cone Edge Composition : Paper cone edge
- Dust Cap Composition: Zurette dust cap
Product Specs
- Item Number: 16203
- Make: Eminence
- Model: Swamp Thang 12" 150W 8Ω
- Condition: Brand New
- Finish: Black
- Categories: parts ⇒ replacement-speakers
- Made In: United States
- MPN: SWAMPTHANG
- UPC: 876358001040
