The Universal Audio 710 Twin-Finity is a unique hybrid mic preamp and DI that fuses vintage tube warmth with modern solid-state clarity in a compact 2U half-rack design. Its continuously variable “Tone Blend” control lets you sweep seamlessly between 100% tube saturation and 100% solid-state precision giving you a wide range of tonal possibilities to get creative with. Built to inspire in the age of bedroom level interfaces that often lack harmonic character, the UA 710 Twin-Finity is sure to elevate your recording game.
Specifications
- Microphone input (female XLR)
- Balanced line input (female XLR)
- Unbalanced instrument input (¼-inch jack)
- Balanced line output (male XLR)
- 12AX7 tube complement
- -15dB pad
- 75Hz high-pass filter
- Maximum power consumption 160mA @120VAC, 20W
- Power requirements 100–240VAC
- Mic input impedance 2k ohms
- Line input impedance 10k ohms
- Hi-Z input impedance 2.2M ohms
- Internal output impedance 600 ohms
- Gain range -∞ to 70dBu
- Mic gain range 10–60dBu
- Line gain range -10–40dBu
- Hi-Z gain range -10–40dBu
- Frequency response 20Hz–100kHz ±0.2dBu (mic, line, Hi-Z)
- Minimum THD+Noise @ +4dBu 0.1% tube / 0.005% solid-state
Video: https://youtu.be/2AkFnPRlcQU
Product Specs
- Item Number: 39809
- Make: Universal Audio
- Model: 710 Twin-Finity
- Condition: Very Good
- Finish: Grey
- Categories: pro-audio ⇒ microphone-preamps
- Year: 2000s
- Made In: United States
- MPN: 39809
